C08LD004 LED street light products adopt the world’s first COC innovative structural combination, breaking the limitations of the traditional aluminum substrate heat sink. It dissipates heat faster, maintains lower chip junction temperature, and provides better stability.

High brightness maintenance rate at longer service life operation. The unique structure design of the products is innovative, patented “Independent Pixel Heat Sink”, which is water-proof, moisture-proof, transparent heat, easily to assemble and maintain.

Product Specification
· Model: C08LD004
· IP Rating: IP66
· Luminous Efficacy: 130lm/W
· CRI: ≥70
· Power Factor: ≥0.95
· Wattage: 25W ~ 180W
· Input Voltage: 90 ~ 264V AC
· Color Temperature: 3000K ~ 6000K
· Working Temperature: -40°C ~ 55°C
· Working Humidity: 10%~95%RH, non-condensing
· Service Life: 50000 hours
· Material: Aluminum Alloy + Ceramic Pixel + PC

Applications:
Sidewalks, squares, factory areas, pedestrian streets, cycleways, emergency lanes, residential roads, primary roads, country roads, parks, highways, bridges, expressways, urban elevated roads, arterial roads, and so on.
